Measurement objects Whole blood or hemolysis sample Measured items Fast Mode: HbA1c (Stable HbA1c, S-A1c) and HbF
Variant Mode: HbA1c (Stable HbA1c, S-A1c) and HbF (HbS and HbC separation and HbE and HbD detection can be performed). Measurement principle Reversed-phase cation exchange chromatography Measurement wavelength 420 nm/500 nm (Dual-wavelength colorimetry) Resolution 0.1% Ratio, 1 mmol/mol Measurement range HbA1c: 3 – 20%, 9 – 195 mmol/mol
HbF: 0 – 100% Processing speed Variant mode: 160 seconds/test
Fast mode: 100 seconds/test Sample consumption Whole blood sample: Approximately 4µL
Anemia sample: Approximately 8 µL
Hemolysis sample: Approximately 350 µL Sample container Sample tube:
(12.3 or 15 mm in outer diameter) × (75 to 100 mm in height)
Sample cup: 500 µL Sample supply Piercing sampling Compatible rack type ARKRAY racks (for 5 samples) Operating environment Temperature: 10 – 30°C;
Humidity: 20 – 80% RH (No condensation) Display 20 digits × 2 lines LCD Printer For use with 58-mm width thermal printer paper Number of measurement samples Maximum 10 samples Power requirements AC 100 – 240 V±10%, 50/60 Hz Dimensions 330 (W) × 515 (D) × 485 (H) mm
(Not including protrusions, eluent packs and hemolysis washing solution bottle)
